| Fin Count (every 4") | 64 |
| EOC Inlet Diameter (IN) | 1/2-20UNF |
| Outlet Diameter (in) | 1.30 |
| Bottom Header | 2.09x15.71 |
| Transmission Oil Cooler Included | Yes |
| Tube Count (Every 4") | 10 |
| Engine Oil Cooler Included | Yes |
| EOC Outlet Type | adapter |
| Fin Count (Every 4") | 64 |
| Core Length (IN) | 26.61 |
| Tube Count (every 4") | 10 |
| Inlet Diameter (in) | 1.30 |
| TOC (Yes/No) | Yes |
| Flow Configuration | Crossflow |
| Top Header | 2.09x15.71 |
| Transmission Oil Cooler Type | Plate Oil Cooler |
| TOC Distance (IN) | 10.00 |
| Core Height (in) | 14.88 |
| Remarks | STAMPED w/ NMC or NMS |
| Core Material | Aluminum |
| Outlet Connection Type | Hose Clamp |
| EOC Inlet Diameter (mm) | 1/2-20UNF |
| inlet connection type | Hose Clamp |
| Toc Outlet Diameter (in) | 0.35 |
| EOC (Yes/No) | Yes |
| Fin Wave Height (IN) | 0.31 |
| TOC Inlet Type | Tube fitting |
| Tube Width x Height | 26x2 |
| EOC Distance (IN) | 9.49 |
| No. of Rows | 1 |
| TOC Outlet Type | Tube fitting |
| EOC Outlet Diameter (IN) | 1/2-20UNF |
| Find Wave Pitch | 3.2 |
| Toc Inlet Diameter (in) | 0.35 |
| Engine Oil Cooler Type | Concentric Oil Cooler |
| Total Tube Count | 37 |
| TOC Type | Plate Oil Cooler |
| EOC Type | Concentric Oil Cooler |
| Core Thickness (in) | 1.02 |
| EOC Inlet Type | adapter |
| Total Fin Row Count | 38 |
| Part Terminology | Radiator |
