| Solid Or Vented Type Rotor | Vented |
| Nominal Thickness | 38.0 |
| Outside Diameter | 346.8 |
| Mounting Bolt Hole Quantity | 8 |
| Discard Thickness | 36.4 |
| Overall Height | 99.8 |
| Heavy Duty Supplier | Yes |
| Outer Diameter Inches | 13.654 |
| Center Hole Diameter Inches | 5.087 |
| Overall Height Inches | 3.929 |
| Bolt Circle Diameter Inches | 6.693 |
| VIO | 1142133 |
| Rotor Type | Vented |
| Bolt Holes | 8 |
| New Thickness Inches | 1.496 |
| Center Hole Diameter MM | 129.2 |
| New Thickness MM | 38 |
| Minimum Thickness MM | 36.4 |
| Outer Diameter MM | 346.8 |
| Bolt Circle Diameter MM | 170 |
| Minimum Thickness Inches | 1.433 |
| Overall Height MM | 99.8 |
| California Proposition 65 | Warning: Cancer and Reproductive Harm – www.P65Warnings.ca.gov |
| Part Terminology | Disc Brake Rotor |
