| Coupling Description | MegaCrimp Female British Standard Parallel Pipe O-Ring Swivel - 90 Bent Tube |
| Seal Type | Mated Angle w/O-Ring |
| Heavy Duty Supplier | Yes |
| Seated Angle | 30 |
| Hose Inside Diameter (in) | .375 |
| Gender | Female |
| Drop (in) - T | 1.26 |
| Hose Recommendation | Can Accommodate Various Hose Outside Diameters on Both One-Wire & Two-Wire Braid Hydraulic Hose |
| Nut Hex (mm) - H2 | 22 |
| Inside Diameter | 9.5 |
| Length (in) | 2.44 |
| Drop (mm) - T | 32 |
| Alliance Keywords | hydraulic hose, hydraulic fitting, hydraulic coupler, Boyau hydraulique, Accouplement |
| Cut Off (mm) - C | 34 |
| Industrial Description | 6G-6FBSPORX90 |
| Cut Off (in) - C | 1.34 |
| Hose Inside Diameter (mm) | 9.5 |
| Drop Length | 32 |
| Termination | British |
| Thread Size | 3/8-19 |
| Seat Angle | 30 |
| Bent Tube Angle | 90 |
| Length | 2.44 |
| O-Ring Location | On Female w/Inverted Nose Seat |
| Swivel | Yes |
| Length (MM) | 61.9 |
| Part Terminology | Hydraulic Coupling / Adapter |
