| Burst Pressure | 16000 |
| EN Specification | N/A |
| Dash Size | 12 |
| Heavy Duty Supplier | Yes |
| Hose Inside Diameter (in) | .75 |
| Coupling Recommendation | GlobalSpiral, MegaCrimp |
| Dispensing Type | Reel |
| Inside Diameter | .75 |
| Minimum Burst Pressure (psi) | 16000 |
| Cover Material | Synthetic Rubber - Polychloroprene - Type A - Color Coded Layline |
| Reinforcement | Two Braids, High-Tensile Steel Wire |
| Maximum Working Pressure (psi) | 4000 |
| ISO Specification | 18752 Grade C, 11237 R19 |
| Hose Material | Nitrile - Type C |
| Alliance Keywords | hydraulic hose, hydraulic fitting, hydraulic coupler, Boyau hydraulique, Accouplement |
| Industrial Description | 12M4KHXREEL |
| Cover Color | Black |
| Temperature Rating | -40 Deg. F to +250 Deg. F (-40 Deg. C to +121 Deg. C) |
| Inside Diameter (in) | .75 |
| Minimum Bend Radius (in) | 4.7 |
| Maximum Working Pressure | 4000 |
| Color | Black |
| Material | Synthetic Rubber - Polychloroprene - Type A - Color Coded Layline |
| Tube Description | Black, Oil-Resistant, Synthetic Rubber |
| Reinforcement Material | Two Braids, High-Tensile Steel Wire |
| Type | Hydraulic Hose |
| Tube Material | Nitrile - Type C |
| Hose Outside Diameter (in) | 1.17 |
| Length | 220 |
| Product Type | Global M4KH Mega4000 Hose - High-Temp - SAE 100R19 |
| SAE Specification | 100R19 |
| Outside Diameter (In) | 1.17 |
| Temperature Range | -40 Deg. F to +250 Deg. F (-40 Deg. C to +121 Deg. C) |
| Hose Pressure Description | High Pressure |
| Cover Type | Type A - Flame, Oil, Abrasion & Weather Resistant |
| Outside Diameter | 1.17 |
| Part Terminology | Hydraulic Hose |
