Product Details
expand_less
| Wiring Harness Included |
No |
| FAQ_Q5 |
How do moisture sensitive wipers work? |
| FAQ_Q4 |
How can I determine if my vehicle is equipped with a moisture sensitive wiper motor? |
| Features and Benefits |
Weak solder points are 100% reflowed to extend life expectancy |
| Washer Pump Included |
No |
| Is or contains a bulb? |
No |
| FAQ_Q1 |
The wiper motor continues to stop in the middle of the windshield. What's causing this to happen? |
| FAQ_Q3 |
Why won't the wiper motor work? I have everything hooked up properly. |
| Mounting Hole Quantity |
3 |
| FAQ_Q2 |
I just installed a new wiper motor and put my old washer pump on and the motor does not work. Is the motor defective? |
| Is Prop Sixty Five Affected |
No |
| Package Contents |
Wiper Motor; Instruction Sheet |
| Is the item CARB affected |
No |
| Terminal Gender |
Male |
| Does it require SDS |
No |
| Wiper Speeds |
2 |
| First Application Year |
2008 |
| Terminal Quantity |
12 |
| Is item a chemical? |
No |
| SDS Required |
No |
| FAQs |
Why won't the wiper motor work? I have everything hooked up properly. |
| Is Or Contains A Battery |
No |
| Product Condition |
Remanufactured |
| Is the item CARB affected? |
No |
| Terminal Type |
Blade |
| Connector Gender |
Female |
| Material |
Cast Aluminum |
| Contains Electronic Components? |
Circuit Board |
| FAA_A4 |
Most vehicles equipped with this feature have a rain sensor permanently mounted to the inside of the windshield in front of the rear view mirror. |
| FAA_A5 |
A moisture sensor monitors rainfall accumulation on the windshield and provides input to the windshield wiper motor control module. The windshield wiper control module adjusts the wiper motor speed accordingly. |
| Mounting Type |
Direct Bolt |
| FAA_A2 |
The motor is NOT defective. There are some wiper motors that will not operate if the washer pump is defective. This may be the cause of the original motor problem. Bench test wiper motor and washer pump before replacing either. |
| FAA_A3 |
Check the wiring harness ground, terminal ground lug or ground strap. If the motor still does not operate properly, check the switch and switch circuit. |
| FAA_A1 |
If the motor does not have hidden wiper blades, the most likely cause of parking misalignment is the crank arm position. Adjust the crank arm angle on the motor shaft to park wipers at bottom of windshield. Refer to a vehicle specific service manual or online material for the "hidden park" reset procedure. |
| Is Or Contains A Bulb |
No |
| Prop 65 |
NO |
| Is or contains a battery? |
No |
| Contains Electronic Components |
Circuit Board |
| E-Waste |
Yes |
| Is Item A Chemical |
No |
| Part Terminology |
Wiper Motor |
Features & Benefits
expand_more
CARDONE's legacy began in 1970 when its first product offering was released − Remanufactured Wiper Motors. Since then, the CARDONE name has become synonymous with high-quality, remanufactured products. Every CARDONE wiper motor is re-engineered, built and tested to match O.E. performance. For nearly half a century, CARDONE Remanufactured Wiper Motors have provided rock-solid reliability that you can trust for the long haul.
Application Summary
expand_more
Ford Escape 2012-08, Expedition 2014-08, Explorer 2010-08, Explorer Sport Trac 2010-08, F-150 2010-08, Flex 2013-09, Focus 2011-08, Lobo 2010-08, Mustang 2014-08, Taurus 2012-08, Taurus X 2009-08; Lincoln Mark LT 2008, MKS 2012-09, Navigator 2008, Town Ca
